P/N: CX4800-56F-EU0101F

Комутатор, ZyXEL CX4800-56F, EU, 48-port 10/25G L3 Aggregation Fiber Switch with 8 100G Uplink (with 2 AC power supply)

ZyXEL >> ZyXEL CX4800-56F Препоръчителен сервиз

Препоръчителен сервиз
ПОЛИКОМП, тел. 02 814 4188, Гаранционна процедура

Характеристики

Суич, тип	Fixed Port
Общ брой портове	56
Основни портове, тип	48 x 10/25GE SFP28
Power Over Ethernet (PoE)	-
Uplink портове	8x100G QSFP28
Свободни (10GB) слотове	-
Управление	via 100/1000BASE-T RJ-45 port for out-of-band IP management; Support NebulaFlex Pro for hybrid mode; Standalone management by Web interface; Cloud management by Nebula Control Center; Management through console, ssh, telnet, SNMP
Stackable	Physical stacking up to 2 units
Fans	Up to 4 field-replaceable, hot-swappable fans
Захранване	Dual hot-swappable AC/DC power supply modules
Routing	Up to 2-unit stacking with Layer 3 static, policy-based, and dynamic routing; IPv4 static route
Памет (Flash, RAM)	64MB/8GB
Капацитет за маршрутизиране/превключване, Gbps	4 Tbps
Пропускателна способност, Mpps	2 Bpps
MAC адреси	32K
VLAN (брой, стандарти)	802.1Q static VLANs/dynamic VLANs: 4K/4K; Port/MAC/Protocol/IP subnet-based VLAN; Private VLAN; VLAN trunking/translation/ingress filtering; 802.1ad VLAN stacking (QinQ)
QoS	No. of hardware queues per port: 8; 802.1p; Storm control: Broadcast, Multicast, Unknown Unicast (DLF); Rate limiting, per IP/TCP/UDP per port; 802.1p Class of Service; Policy based prioritization and etc.
L3 мрежови стандарти	IEEE 802.1D Spanning Tree Protocol (STP); IEEE 802.1w Rapid Spanning Tree Protocol (RSTP); IEEE 802.1s Multiple Spanning Tree Protocol (MSTP); IEEE 802.3ad LACP
IPv6 functionality	ACL packet filtering (IPv4/IPv6); Multiple RADIUS servers (IPv4/IPv6); IPv6 Management; IPv6 Interface; IPv6 MLD Snooping; IPv6 static route; IPv6 default routing; IPv6 ECMP; IPv6 Neighbor Discover
Сигурност	802.1x; Port security; MAC authentication; Layer 2 MAC filtering; Layer 3 IP filtering; Layer 4 TCP/UDP socket filtering; Static MAC forwarding; Multiple RADIUS servers (IPv4*/IPv6); Multiple TACACS+ servers; Login authentication by RADIUS/TACACS+
Размери (Ш, Д, В), mm	440 x 489 x 45 mm
Опция за монтаж	Rackmount
Гаранция	99 месеца
