P/N: DS-3E1318P-EI/M

Комутатор, HikVision 16 Port Fast Ethernet Smart POE Switch, 16 x 10/100M PoE ports, 1 x Gigabit RJ45 port, 1 x Gigabit combo, Total PoE Power Budget 130 W, Up to 300 m Long Range PoE Transmission, 6 kV Surge Protection

HikVision 16 Port Fast Ethernet Smart POE Switch, 16 x 10/100M PoE ports, 1 x Gigabit RJ45 port, 1 x Gigabit combo, Total PoE Power Budget 130 W, Up to 300 m Long Range PoE Transmission, 6 kV Surge Protection

HikVision HiWatch Series >> HikVision 16 Port Fast Ethernet Smart POE Switch Препоръчителен сервиз

Препоръчителен сервиз
ПОЛИКОМП, тел. 02 814 4188, Гаранционна процедура

Характеристики

Суич, тип	Fixed Port
Общ брой портове	18
Основни портове, тип	16x10/100Base-TX
Power Over Ethernet (PoE)	IEEE 802.3af, IEEE 802.3at PoE Standard; PoE: Ports 1 to 16; Max. Port Power: 30 W; PoE Power Budget: 130 W
Uplink портове	1 dual personality, 1x10/100/1000Base-T
Свободни (10GB) слотове	No
Управление	Remote management via Hik-Partner Pro; Management via Hik-Central Pro; Device management via web; DHCP Client; Port mirroring
Stackable	No
Fans	Fanless design
Захранване	100-240 V AC, 50/60 Hz, Max. 3 A; Max. Power Consumption: 150 W
Routing	Layer 2 Only
Памет (Flash, RAM)	-
Капацитет за маршрутизиране/превключване, Gbps	Whole-Device Performance: 9.2 Gbps, Port Performance: 7.2 Gbps
Пропускателна способност, Mpps	Whole-Device Performance: 6.84 Mpps, Port Performance: 5.36 Mpps
MAC адреси	16 000 MAC address table size
VLAN (брой, стандарти)	VLAN is used for network scale planning and network health improvement; Support 802.1Q; Configurable VLAN ID from 1-4094; Support Trunk, Access port mode; Support Max. 4094 VLAN
QoS	-
L2 мрежови стандарти	IEEE 802.1Q, IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1w, IEEE 802.1ab
L3 мрежови стандарти	-
IPv6 functionality	-
Сигурност	6 kV Surge Protection, STP/RSTP loop prevention, cable detection to locate failure
Размери (Ш, Д, В), mm	440.00 x 44.00 x 220.80 mm
Опция за монтаж	Rackmount
Гаранция	24 месеца
