P/N: DXS-3400-24TC

Комутатор, D-Link 20-Port 10GBASE-T/SFP+ and 10GBASE-T/SFP+ Combo Port

D-LINK мрежови продукти >> D-Link 20-Port 10GBASE-T/SFP+ and 10GBASE-T/SFP+ Combo Port Препоръчителен сервиз

Препоръчителен сервиз
ПОЛИКОМП, тел. 02 814 4188, Гаранционна процедура

Характеристики

Суич, тип	Fixed Port
Общ брой портове	24
Основни портове, тип	20x10GBase-T
Power Over Ethernet (PoE)	No
Uplink портове	4 dual personality
Свободни (10GB) слотове	No
Управление	Web-based GUI, CLI, Telnet Server/Client, TFTP Client, FTP Client, Traffic Monitoring, SNMP (Supports v1/v2c/v3), SNMP Trap, System Log, CPU Monitoring, RMONv1, RMONv2, Trusted Host, Debug command, sFlow, Switch Resource Management (SRM), LLDP & LLDP-MED
Stackable	Physical Stacking: Up to 80G stacking bandwidth, Up to 4 switches in a stack, Ring/chain topology support; Virtual Stacking/Clustering of up to 32 units: Supports D-Link Single IP Management
Fans	Three hot-swappable fan trays provide N+1 cooling redundancy
Захранване	Two AC/DC hot-swappable power modules for 1+1 power redundancy and load sharing
Routing	Layer 3 RIP
Памет (Flash, RAM)	-
Капацитет за маршрутизиране/превключване, Gbps	480 Gbps
Пропускателна способност, Mpps	357.14 Mpps
MAC адреси	48000 MAC address table size
VLAN (брой, стандарти)	802.1Q, 802.1v, Double VLAN (Q-in-Q), Selective Q-in-Q, Port/MAC/Subnet-based VLAN, Private VLAN, VLAN Group (Max. 4K static VLAN groups, Max. 4094 VIDs), ISM VLAN (Multicast VLAN), GVRP (Up to 4094 dynamic VLANs), Voice VLAN, Auto Surveillance VLAN
QoS	802.1p Quality of Service (QoS), 8 queues per port, Queue handling (Strict, Weighted Round Robin (WRR), Strict + WRR, Deficit Round Robin (DRR), Weighted Deficit Round Robin (WDRR)), Bandwidth Control, Congestion Control
L2 мрежови стандарти	IEEE 802.3u, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3x, IEEE 802.1X, IEEE 802.1Q, IEEE 802.1v, IEEE 802.1AX, IEEE 802.1p, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.3ah, IEEE 802.1ag
L3 мрежови стандарти	Static Routing: Max. 256 IPv4 entries, Max. 128 IPv6 entries, Supports route redistribution, Supports secondary route; Default Routing; Policy-based Route (PBR); Bidirectional Forwarding Detection (BFD); RIP (RIP v1/v2, RIPng); Route Redistribution
IPv6 functionality	IPv6 Neighbor Discovery (ND), IPv6 Tunneling - Static, ISATAP, GRE, 6to4
Сигурност	Port Security, Broadcast/Multicast/Unicast Storm Control, D-Link Safeguard Engine, DHCP Server Screening, IP-MAC-Port Binding (IMPB), Dynamic ARP Inspection, IP Source Guard, DHCP Snooping, DHCPv6 Guard, BPDU Attack Protection, DOS Attack Prevention, SSH
Размери (Ш, Д, В), mm	441 x 380 x 44
Опция за монтаж	Rackmount
Други	10/100/1000BASE-T RJ-45 Ethernet for out-of-band IP management, RJ45 and Mini USB console ports for out-of-band CLI management, 1 USB Port
Гаранция	99 месеца
