P/N: C9300-48S-E

Комутатор, Cisco Catalyst 9300 48-port 1G SFP with modular uplinks, Network Essentials

Задължителен е минимум 3-годишен лиценз DNA Advantage!

Cisco Enterprise and Service Providers - Borderless Networks >> Cisco Catalyst 9300 48-port 1G SFP with modular uplinks Препоръчителен сервиз

Препоръчителен сервиз
ПОЛИКОМП, тел. 02 814 4188, Гаранционна процедура

Характеристики

Суич, тип	Modular
Общ брой портове	48
Основни портове, тип	48x 1G SFP
Power Over Ethernet (PoE)	No
Uplink портове	Modular Uplinks
Свободни (10GB) слотове	-
Управление	Cloud management and monitoring; WebUI
Stackable	Designed for stacking switches as a single virtual switch, enabling customers to have a single management plane and control plane for up to 448 access ports.
Fans	Three field-replaceable fans and support (N+1) redundancy.
Захранване	Redundant; Default AC power supply: 715W AC
Routing	High-Performance IP routing; Total routed ports: 448
Памет (Flash, RAM)	DRAM: 8 GB; Flash: 16 GB; Packet buffer per SKU: 16 MB buffer for 24-or 48-port Gigabit Ethernet models
Капацитет за маршрутизиране/превключване, Gbps	256 Gbps, Switching capacity with stacking: 736 Gbps
Пропускателна способност, Mpps	190.47 Mpps; Forwarding rate with stacking: 547.62 Mpps
MAC адреси	32 000
VLAN (брой, стандарти)	VLAN IDs: 4094; IEEE 802.1Q VLAN
QoS	QoS scale entries: 5 120; Superior QoS (802.1p Class of Service (CoS), DSCP, SRR, CIR)
L2 мрежови стандарти	IEEE 802.3 ab/z/bz/an/x
L3 мрежови стандарти	IEEE 802.1D, RMON I and II standards, SNMPv1, v2c, and v3
IPv6 functionality	IPv6 routing entries: 16 000
Сигурност	ETA, SUDI, AES-256 MACsec encryption, IPsec encryption, Trustworthy solutions built with Cisco Trust Anchor Technologies; Cloud Security: Umbrella DNS Integration, ASAc
Размери (Ш, Д, В), mm	444 x 488 x 43 mm
Опция за монтаж	Rackmount
Други	Network Essentials
Гаранция	99 месеца
