P/N: C9200L-48T-4X-E

Commutator/ Switch, Cisco Catalyst 9200L 48-port Data 4x10G uplink Switch, Network Essentials

Cisco Enterprise and Service Providers - Borderless Networks >> Cisco Catalyst 9200L 48-port Data 4x10G uplink Switch Recommended service

Recommended service
ПОЛИКОМП, тел. 02 814 4188, Гаранционна процедура

Characteristic

Switch, type	Fixed Port
Total number of ports	52
Мain ports, type	48x10/100/1000Base-T
Power Over Ethernet (PoE)	No
Uplink ports	4x10GBase-T
Open (10GB) slots	No
Management	SNMPv1, SNMPv2c, and SNMPv3; RMON I and II standards; Internet Group Management Protocol (IGMP); CLI; TCP; UDP
Stackable	Cisco StackWise-80 stacking ports: copper-based Cisco StackWise cabling, Stacking hardware (C9200L-STACK-KIT=), Supported stack members: Other C9200L models with same license level (8 Number of members)
Fans	Fixed redundant
Power supply	Dual field-replaceable power supplies, Default primary AC power supply: PWR-C5-125WAC
Routing	Layer 3 Advanced
Memory (Flash, RAM)	Flash memory: 4 GB; RAM: 2 GB DRAM
Routing/Switching capacity, Gbps	176 Gbps
Throughput, Mpps	261.9 Mpps
MAC addresses	16000 MAC address
VLAN (number, standards)	VLAN IDs: 1024; IEEE 802.1Q VLAN
QoS	Granular wireless bandwidth management and fair sharing,802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification,Shaped Round Robin (SRR) scheduling,Committed Information Rate (CIR), and eight egress queues per port
L2 network standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x
L3 network standards	IP unicast routing protocols: Static, Routing Information Protocol Version 1 [RIPv1], and RIPv2, RIPng, Open Shortest Path First [OSPF]
IPv6 functionality	IPv6 routing (using OSPFv3 and EIGRPv6) is supported in hardware for maximum performance; IPv6 addressing is supported on interfaces with appropriate show commands for monitoring and troubleshooting
Security	Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
Dimensions (W, D, H), mm	445 x 288 x 44
Мounting option	Rackmount
Other	Задължителен е минимум 3-годишен лиценз DNA Essentials.
Warranty	99 months
