P/N: DGS-3130-30S

Комутатор, D-Link 24 SFP ports Layer 3 Stackable Managed Gigabit Switch with 2x10GBASE-T ports and 4xSFP+ ports

Декларация за съответствие D-Link DGS-3130 series_BG.pdf

D-LINK мрежови продукти >> D-Link 24 SFP ports Layer 3 Stackable Managed Gigabit Switch with 2x10GBASE-T ports and 4xSFP+ ports Препоръчителен сервиз

Препоръчителен сервиз
ПОЛИКОМП, тел. 02 814 4188, Гаранционна процедура

Документи

207 341 BD-Link Warranty Regulatory Notices_BG.pdf

Характеристики

Суич, тип	Fixed Port
Общ брой портове	30
Основни портове, тип	24xSFP
Power Over Ethernet (PoE)	No
Uplink портове	4x10GE SFP, 2x10GBase-T
Свободни (10GB) слотове	No
Управление	Web-based GUI, Command Line Interface (CLI), SNMP, RMON v1/v2, LLDP/LLDP-MED, BootP/DHCP Client, DHCP, Flash File System, D-Link Discover Protocol (DDP), Debug command, NTPv3/v4, Command Logging, Ping/Traceroute for IPv4/IPv6, Password recovery/encryption
Stackable	4 Stacking Ports; Physical stacking: Stacking Lite, Up to 80 Gbps stacking bandwidth, Ring/chain topology support; Virtual stacking: D-Link Single IP Management (SIM), Up to 32 units per virtual stack
Fans	3x Smart fans
Захранване	Power Input: 100 to 240 V AC 50/60 Hz; Max Power Consumption: 65.01 W, Standby - 22.77 W; Optional Redundant Power Supply: DPS-500A
Routing	Layer 3 Advanced
Памет (Flash, RAM)	Packet Buffer Memory: 2 MB
Капацитет за маршрутизиране/превключване, Gbps	168 Gbps
Пропускателна способност, Mpps	125 Mpps
MAC адреси	16000 MAC address table size
VLAN (брой, стандарти)	VLAN Group: Max. 4K VLAN groups, Max. 1~4094 VIDs; GVRP (Max. 4K dynamic VLAN groups); Double VLAN (Q-in-Q); 802.1Q; Port-based VLAN; 802.1v Protocol-based VLAN; MAC-based VLAN; VLAN translation; Multicast/Asymmetric/Private VLAN; VLAN Trunking;Super VLAN
QoS	802.1p Quality of Service; 8 queues per port; Queue Handling - Strict, Weighted Round Robin (WRR), Strict + WRR, Weighted Deficit Round Robin (WDRR); Policy Map - Remark 802.1p priority, Remark IP precedence/DSCP, Time based QoS; Congestion Control - WRED
L2 мрежови стандарти	IEEE 802.1p, IEEE 802.1X, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1v
L3 мрежови стандарти	Static Route, RIPv1/v2/ng, OSPFv2/v3
IPv6 functionality	IPv6 traffic class, IPv6 Flow Label, IPv6 Snooping, IPv6 Route Advertisement (RA) Guard, IPv6 ND Inspection
Сигурност	Broadcast/Multicast/Unicast Storm Control, D-Link Safeguard Engine, Port Security - Supports up to 64 MAC addresses per port, Dynamic ARP Inspection (DAI), DHCPv6 Guard, IP Source Guard, Duplicate Address Detection (DAD), Traffic Segmentation, SSL, SSH
Размери (Ш, Д, В), mm	440 x 250 x 44 mm
Опция за монтаж	Rackmount
Други	10/100/1000BASE-T RJ-45 port for out-of-band CLI management, 10/100/1000BASE-T RJ-45 port for out-of-band IP management, 1x USB 2.0 Type A port
Гаранция	99 месеца
