P/N: PDUMH32HVNET

Filter, Tripp Lite by Eaton 7.4kW Single-Phase Switched PDU, LX Interface, 230V Outlets (16-C13), IEC-309 Blue 230V 32A, 3.6m Cord, 2U Rack-Mount, TAA

Recommended service
Мундус Сървисиз АД, тел. 0883 888 333, адрес: гр. София, бул. Искърско шосе 7, Търговски Център „Европа“, сграда 9, етаж -1, e-mail: ups_service@mundus.bg

Characteristic

Input voltage, V	230V AC
Input frequency, Hz	50/60 Hz
Input current, A	32A
Max. power, kW	7.4kW
Number of phases	1
Input connection	IEC-309 32A BLUE (2P+E)
Number of outputs	16
Inference type	16x IEC C13; RJ45 Network port, Micro-USB Configuration port, USB A
Cable length, m	3.66m
Security	Two 20A circuit breakers protect 8 outlets each
Installation	Mounting flanges support installation in 2 and 4 post racks, with additional support for wall-mount and under-counter installation formats; Mounting ears are reversible for front or rear facing rackmount installation; Included cord retention brackets
Form factor	2U
Standards	EN 60950-1; RoHS; CE (Europe); FCC Part 15 Class A (USA); Trade Agreements Act (TAA)
Dimensions (W, D, H), mm	445 x 317.5 x 89 mm
Weight, g	6210g
Color	Black
Warranty	24 months
